Coastal private villa infinity pool lighting at night.

Model & Quantity: SYA-201-12W × 18 fixtures

1.Electrical: DC24V SELV; centralized IP65 power cabinet with 4 circuits; 2 kV surge protection.

2.Optics: CCT 3000K; 120° frosted anti-glare lens; CRI ≥ 80; IES available.

3.Installation: Recessed cup in pool wall at −450 mm from waterline; center spacing 1.4 m; 316L brushed trim; dual O‑rings + full potting;

4.marine-grade rubber cable 2×1.0 mm², 8 m each.

5.Control: Timer + PWM dimming (Night Swim 100%, Cleaning 30%).

6.Acceptance Metrics: Average illuminance 82 lx on water surface; uniformity 0.64; low perceived glare; no leakage after 12 months continuous immersion.

7.Outcome: Soft, uniform blanket of light across the pool; clear steps and edges; low maintenance, clean mirror-like reflections.
